SC/APC Fixed Fiber Optic Attenuators
Fixed SC/APC fiber optic attenuators designed to reduce optical power in singlemode networks, available in 5 dB, 10 dB, 15 dB, and 20 dB options.
These SC/APC Fixed Fiber Optic Attenuators are designed to reduce optical signal strength in singlemode fiber networks where excessive power could overwhelm receiving equipment. Available in 5 dB, 10 dB, 15 dB, and 20 dB attenuation levels, they support 1310 nm and 1550 nm wavelengths, feature APC polishing with a return loss of at least 65 dB, and provide wavelength-independent attenuation for dependable use in telecom systems, fiber distribution networks, test environments, and other optical installations.
- Available in 5 dB, 10 dB, 15 dB, and 20 dB attenuation levels
- Supports 1310 nm and 1550 nm operating wavelengths
- APC polish with return loss of at least 65 dB
- SC female-to-female configuration
- Wavelength-independent attenuation design
- Helps prevent optical receiver saturation
- Supports lower bit error rates in fiber links
- Helps protect sensitive receiving equipment
- Useful for balancing signal power in network installations
- Provides a simple solution for managing excessive optical power
